Secrets

Table of Content

• Secrets overview
• Secrets example

Secrets overview

Automation scripts always need secrets, i.e. tokens or credentials to access infrastructure devices, services, etc. Kriten provides facility to store secrets as Kubernetes secrets and makes them available at the time of Job launching as files in /etc/secret directory and also as environmental vars. Secrets are provisioned by admin users and not visible to executors of Tasks.

Secrets are associated with Runners. Runner defines execution environment - code repository with automation code, container image with all the packages and dependencies needed to run automation code, etc.

POST /api/v1/runners

{
  "name": "kriten-examples",
  "image": "python:3.9-slim",
  "gitURL": "https://github.com/kriten-io/kriten-community-toolkit.git",
  "secret": {
      "username": "admin",
      "password": "P@55w0rd!",
      "super_secret": "1234567890!"
  }
}

Secrets are defined in the secret field of the runner and can be created at the time of Runner creation or patching (update). After secrets created - they are obfuscated and won't be visible via Kriten.

Getting Runner info:

GET /api/v1/runners/kriten-example

Produces response, where secrets are hidden and can't be observed.

{
    "secret": {
        "password": "************",
        "super_secret": "************",
        "username": "************"
    },
    "name": "kriten-examples",
    "image": "python:3.9-slim",
    "gitURL": "https://github.com/kriten-io/kriten-community-toolkit.git",
    "token": "",
    "branch": "main"
}

Kriten provides endpoint for CRUD operation of secrets as /api/v1/runners/$RUNNER_NAME/secret, i.e. for above /api/v1/runners/kriten-examples/secret.

• Getting secrets

GET /api/v1/runners/kriten-examples/secret

Example response body:

{
    "password": "************",
    "super_secret": "************",
    "username": "************"
}

• Delete all secrets associated with the runner:

DELETE /api/v1/runners/kriten-examples/secret

• Add secrets to the runner:

POST /api/v1/runners/kriten-examples/secret

Body of request:

{
    "username": "admin",
    "password": "P@55w0rd!",
    "super_secret": "1234567890!"
}

That will add those secrets to the kriten-examples runner.

• Update secrets

POST /api/v1/runners/kriten-examples/secret

Body of request:

{
    "mysecret": "sup3r53cr3t!"
}

Following rules are applied at updating secrets:

Condition	Behaviour
secret key and non-empty value already present in stored secrets	No change
secret key and non-empty value == "**" (obfuscated) present or not	No change
secret key and empty value "" for existing secret	Delete stored secret with matching key
secret key and non-empty value non-existing secret	Add new secret

Secrets Example

We will demonstrate above on example with curl commands. We will create runner with secretes as above, add a new secret to existing secrets and delete that secret after.

• Login into Kriten.

We will login into Kriten with default credentials as example.

curl -c ./token.txt -X POST $KRITEN_URL'/api/v1/login' \
--header 'Content-Type: application/json' \
--data '{
  "username": "root",
  "password": "root",
  "provider": "local"
}'

• Create Runner with secrets.

curl -b ./token.txt -X POST $KRITEN_URL'/api/v1/runners' \
--header 'Content-Type: application/json' \
--data '{
  "name": "kriten-examples",
  "image": "python:3.9-slim",
  "gitURL": "https://github.com/kriten-io/kriten-community-toolkit.git",
  "secret": {
      "username": "admin",
      "password": "P@55w0rd!",
      "super_secret": "1234567890!"
  }
}'

• Get secrets.

curl -b ./token.txt -X GET $KRITEN_URL'/api/v1/runners/kriten-examples/secret'

Body of response:

{
    "password": "************",
    "super_secret": "************",
    "username": "************"
}

We can also observe secrets by getting runner details as following:

curl -b ./token.txt -X GET $KRITEN_URL'/api/v1/runners/kriten-examples'

Body of response:

{
    "secret": {
        "password": "************",
        "super_secret": "************",
        "username": "************"
    },
    "name": "kriten-examples",
    "image": "python:3.9-slim",
    "gitURL": "https://github.com/kriten-io/kriten-community-toolkit.git",
    "token": "",
    "branch": "main"
}

• Add new secret to the runner secrets.

curl -b ./token.txt -X POST $KRITEN_URL'/api/v1/runners/kriten-examples/secret' \
--header 'Content-Type: application/json' \
--data '{
    "mysecret": "sup3r53cr3t!"
}'

Body of response, where we can see new secret has been added:

{
    "mysecret":"*************",
    "password":"*************",
    "super_secret":"*************",
    "username":"*************"
}

• Delete individual secret.

To delete mysecret we will POST again, but this time make value as empty string "".

curl -b ./token.txt -X POST $KRITEN_URL'/api/v1/runners/kriten-examples/secret' \
--header 'Content-Type: application/json' \
--data '{
    "mysecret": ""
}'

Body of response will return secrets without mysecret:

{
    "password":"*************",
    "super_secret":"*************",
    "username":"*************"
}
